BS250

  • Category:BS Small Standard Machine Series
  • Number of views:460次
  • Release Date:2023/3/28 11:03:43
  • overview


ltems
Unit
BS-250
injection system
 Screw Diameter Kg/cm² Φ22 Φ26 Φ28
 Maximum lnjection Pressure cm³ 2011 1814 1446
 Theoretical Shot Volume g(oz) 38 49 61
Maximum Shot Weight(PS) cm³/sec 36(1.2) 45(1.6) 56(2.0)
lnjection Rate tom 32 37 46


Locking system

 Clamping Force mm 35
 Mold Size mm 355x225
 Minimum Mold Thickness mm 80/160
 Opeining Stroke mm 180
Open Daylight mm 260/340
 Ejector Force tom 1.3
 Ejector Stroke mm 35
Hydaulic System Pressure Kg/cm² 140
other
 Oil Tank Volume L 120
 Electric Power hp(kw) 5(3.7)
 Barrel Heating Power kw 2.7
 Total Wattage kw 6.7
 Machine Dimensions(approx.) m 1.6x0.9x2.3
 Machine Weight(approx.) t 0.9
